NCPXIV

NCPXIV

NEP | United States

NCPXIV is a powerful HD mobile unit.

What’s a Rich Text element?

The rich text element allows you to create and format headings, paragraphs, blockquotes, images, and video all in one place instead of having to add and format them individually. Just double-click and easily create content.

Static and dynamic content editing

A rich text element can be used with static or dynamic content. For static content, just drop it into any page and begin editing. For dynamic content, add a rich text field to any collection and then connect a rich text element to that field in the settings panel. Voila!

How to customize formatting for each rich text
  • Headings, paragraphs, blockquotes, figures, images, and figure captions can all be styled after a class is added to the rich text element using the "When inside of" nested selector system.
  • ‍Headings, paragraphs, blockquotes, figures, images, and figure captions can all be styled after a class is added to the rich text element using the "When inside of" nested selector system.

Headings, paragraphs, blockquotes, figures, images, and figure captions can all be styled after a class is added to the rich text element using the "When inside of" nested selector system.

Vehicle-Specific Information
  • A-Unit
  • 53' long x 13'6" high x 8'6" wide
  • 70' long x 13'6" high x 20' wide - expanded with tractor
  • Street side Expando
  • TRACTOR # 209120, 1XPBDP9X2KD235208, IN – 2725599
  • TRAILER VIN # 1UYVS2534BG018821, PA- PT8858N
  • TOTAL WEIGHT A UNIT 80,000 LBS
  • 400 amp, 208 volt, 3 phase
  • OR
  • 2 200amp, 208 volt, 3 phase
  • B-Unit
  • No Expando
  • TRACTOR # PER EVENT
  • TRAILER VIN # 1JJV532W98L238294, PA- PT8859N
  • TOTAL WEIGHT B UNIT 70,560 LBS
Production
  • GVG Kayenne Classic Switcher, 96 Inputs / 48 Outputs
  • 5 M/E
  • 16 IDPM / eDPM / 2D DPM
  • 32g Still Store
  • 32 ChromaKeyers
  • Flexkey
  • DoubleTake
  • Elite Package
  • K2 Summit available
Communications
  • Adam Intercom System - 112 Ports
  • 15 dual listen beltpacks
  • 20 single muff headsets
  • 11 double muff headsets
  • 13 IFB Beltpacks
  • 6 walkie talkies with 1 base station
  • 1 phone system with 12 lines
  • 4 ring down phone lines
  • 6 TIF - Telephone Interfaces
  • 6 QKT
Cameras
  • 10 Sony HDC1500 Camera
  • 5 Sony HDLA Large Lens Adapter
  • 5 Hard Camera Panhead & Tripod
  • 6 HH Camera Panhead & Tripod
  • 10 CCUs on Board
Lenses
  • 1 Canon 100x9.3 Hard Lens
  • 2 Canon 86x9.3 Hard Lens
  • 2 Canon 75x9.3 Hard Lens
  • 3 Canon Lens 21:1 Hand Held Lens
  • 2 Canon 4.7 Wide angle Lens
  • 6 Canon 4.3 Wide angle Lens
Support Equipment
  • Utah Scientific
  • HD video - 288 inputs x 528 outputs
  • 86 inputs x 86 outputs Embed/De-embed
  • MADI 2 inputs x 2 outputs
  • AES 96 inputs x 39 outputs
  • Analog audio 32 inputs x 64 outputs
  • 36 Utility Frame Syncs/Processors
  • 10 HD Video over Fiber Transmitters
  • 2 Light kits
  • 2 Embedders with 16 Audio Channels
  • 2 De-Embedders 16 Audio Channels
  • Monitors:
  • 8 - 17" LCD, 8 - 9" LCD
Audio
  • Calrec Artemis Beam Digital Audio Console
  • Bluefin 2 High Density Signal Processing
  • 340 Channels with full signal processing
  • 128 Mix busses for Group and Main Outputs
  • 64 Multi-track busses
  • 32 Aux busses
  • 64 Faders
  • 128 analog inputs & 128 analog outputs
  • 32 AES inputs & 32 AES outputs
  • 10 MADI inputs & 10 MADI outputs
  • Console enabled with 1 Dante card
  • 1 Hydra II Field Box
  • 1 Dolby Encoder/Decoder Package
  • 2 Digicart
  • 1 CD Player
Microphones
  • 6 Announcer Headsets
  • 8 Daltech Announce Consoles
  • 18 Short Shotgun Microphones
  • 3 Long Shotgun Microphones
  • 9 Stick Microphones
  • 8 Lavalier Microphones
Record & Playback
  • 2 EVS XT3 12 Channel LSM 10 GB
  • 2 EVS XT3 8 Channel LSM 10 GB
  • 1 EVS XS3 6 Channel Spotbox 10 GB
  • 1 EVS X-File[3]
  • 2 EVS Xhub[3]
  • 1 Panasonic DVCPro HD AJ-HD1800 VTR
  • 1 Sony PDW- F1600 HD XDCAM VTR
  • 7 Video Devices PIX270i
  • 2 DVD Recorder w/ remote control
Graphics
  • 1 Chyron MosiacXL
Cables
  • Mini Triax: 10 -250' 10 -100'
  • Mini Triax Mult: 2
  • DT12 6 -250' 4 -100' 2 -50'
  • 4 DT12 Fanout sets
  • 8 DT12 Feed through boxes
  • 6 Pair Mult 3 -200' 3 -100'
  • Assorted Single Line XLR
  • TAC-12 ST-ST 3 - 250'
  • 5 Pair HD Coax Loom 4 -125'
  • Assorted Single Line Coax
  • 1 sets of 100' 4/0 Camlock Power Cable
NCPXIV Production Monitor Wall
NCPXIV Tape Monitor Wall
NCPXIV Video Monitor Wall
NCPXIV A Floor Plan
NCPXIV B Floor Plan
