XP-1

XP-1

NEP | United States

XP-1 is a powerful small HD Sprinter Van that services the market in Hawaii.

What’s a Rich Text element?

The rich text element allows you to create and format headings, paragraphs, blockquotes, images, and video all in one place instead of having to add and format them individually. Just double-click and easily create content.

Static and dynamic content editing

A rich text element can be used with static or dynamic content. For static content, just drop it into any page and begin editing. For dynamic content, add a rich text field to any collection and then connect a rich text element to that field in the settings panel. Voila!

How to customize formatting for each rich text
  • Headings, paragraphs, blockquotes, figures, images, and figure captions can all be styled after a class is added to the rich text element using the "When inside of" nested selector system.
  • ‍Headings, paragraphs, blockquotes, figures, images, and figure captions can all be styled after a class is added to the rich text element using the "When inside of" nested selector system.

Headings, paragraphs, blockquotes, figures, images, and figure captions can all be styled after a class is added to the rich text element using the "When inside of" nested selector system.

Vehicle-Specific Information
  • Mercedes Sprinter Model 3500e Van
  • 24' Long x 9'3" high x 6'8" wide
  • VIN# WD3PE8CC1C5632589
  • PLATE# CA-04775U1
  • WEIGHT 7,564 LBS
  • 110 volts, Single phase, 30 amps
Production
  • For-A MVS-1000 Hanabi Switcher, 12 inputs / 6 outputs, 1.5 ME
Communications
  • RTS Cronus Matrix System - 32 ports
  • 10 single muff headsets
  • 10 dual muff headsets
  • 4 IFB beltpacks
  • 2 TIF - Telephone Interface
Cameras
  • 5 GVG LDK6000 Camera
  • 2 GVG LDK6000 Super Expander
  • 1 Clock Camera
  • 1 HH Camera Panhead & Tripod
  • 3 Hard Camera Panhead & Tripod
  • Truck wired for 5 CCU's
Lenses
  • 3 Canon Lens 21:1 Hand Held Lens
  • 2 Canon 70x Hard Lens
Support Equipment
  • 3 Utility Frame Syncs/Processors
  • 2 HD Video over Fiber Transmitters
  • Monitors:
  • 1 - 20" Color
Audio
  • Yamaha O 1-V Audio Console, 12 analog inputs, 4 digital inputs, 32 Channels, 16 Faders
  • 1 Digicart
Microphones
  • 4 Announcer Headsets
  • 4 Daltech Announce Consoles
  • 4 Short Shotgun Microphones
  • 4 Long Shotgun Microphones
  • 4 Stick Microphones
  • 4 Lavalier Microphones
  • 1 Parabolic Mic
Record & Playback
  • 1 EVS XT2 6 Channel LSM
  • Other devices as needed on request
Cables
  • Mini Triax: 4 -500' 5 -250' 5 -100'
  • DT12 2 -500' 2 -250' 2 -100' 1 -50'
  • DT12 Fanout Sets: 2
  • DT12 Breakout Boxes: 1
  • TAC-4 ST-ST 1 -1000'
  • 5 Pair HD Coax Loom 2 -125'
  • 2 250' Camplex Cables on spools
  • Assorted Single Line Coax and XLR Cables
