Unit 9 – Middle East

Unit 9 – Middle East

This double-expansion HD OBVAN is controlled by TSL, featuring an Evertz 128×128 core router and a Sony MVS8000G vision mixer. Capable of handling up to 14 cameras, the OB supports 12 SONY HDC 1700 cameras, 2 SONY HDC 1500, and 2 SONY SSM 3300 cameras, as well as 6 wireless systems with control. Additional equipment includes up to 6 EVS replay systems, graphics, and tapeless recorders (“HyperDeck Studio Pro”). The OB is equipped with a Calrec Audio Console with Surround Sound capability and RTS Intercom System.

    What’s a Rich Text element?

    The rich text element allows you to create and format headings, paragraphs, blockquotes, images, and video all in one place instead of having to add and format them individually. Just double-click and easily create content.

    Static and dynamic content editing

    A rich text element can be used with static or dynamic content. For static content, just drop it into any page and begin editing. For dynamic content, add a rich text field to any collection and then connect a rich text element to that field in the settings panel. Voila!

    How to customize formatting for each rich text
    • Headings, paragraphs, blockquotes, figures, images, and figure captions can all be styled after a class is added to the rich text element using the "When inside of" nested selector system.
    • ‍Headings, paragraphs, blockquotes, figures, images, and figure captions can all be styled after a class is added to the rich text element using the "When inside of" nested selector system.

    Headings, paragraphs, blockquotes, figures, images, and figure captions can all be styled after a class is added to the rich text element using the "When inside of" nested selector system.

    VIDEO EQUIPMENT

    CAMERA SYSTEM
    • Sony HDC1700/R (18+)
    SUPER SLOMO CAMERA SYSTEM
    • Sony HDC-3300R (2)
    ULTRA SLOMO CAMERA SYSTEM
    • Ikegami NAC HI-MOTION II
    WIRELESS CAMERA SYSTEM
    • Vislink L1500 (6)
    • DOMO BTX UHD 12G (4)
    CAMERA CONNECTION
    • Fiber Optic Lemo SMPTE
    CAMERA LENSES
    • CANON
    TRIPODS
    • CARTONI
    • VINTEN
    • SACHTLER
    • CAM-GEAR
    HD VISION MIXER
    • Sony MVS 8000 4M/E
    • 51 inout - 48 output
    CHARACTER GENERATOR
    • Vizrt
    • Title box
    PRODUCTION ROOM MONITORS
    • Vutrix QUAD HD 23”inch
    SHADING ROOM MONITORS
    • JVC DT-V1710CG 17inch (3)
    • Blackmagic (20)
    MULTIVIEWER SYSTEM
    • Vutrix quad
    • Evertz
    HD VTRS
    • Sony HDW M2000P (6)
    TAPELESS RECORDERS
    • HyperDeck Studio Pro (10)
    REPLAY SYSTEM
    • EVS XT2
    GLUE
    • Axon
    VIDEO MATRIX
    • Evertz
    • 96 input – 128 output
    OB CONTROL
    • TSL
    • Aurora
    WAVEFORM
    • Tektronix WFM 5000

    AUDIO EQUIPMENT

    AUDIO MIXING CONSOLE
    • Calrec Alpha 5.1 Digital Mixing Console
    • Inputs local Ana:48A + 48B - Outputs: Ana:20
    • Dolby 5.1
    MICROPHONES
    • Sennheiser
    MULTITRACK RECORDING
    • AVID Pro Tools
    AUDIO EFFECTS
    • Yamaha SPX 900
    • 360 SYSTEMS INSTANT REPLAY 2
    AUDIO MEASUREMENT
    • Decibel
    • VU meter
    INTERCOM SYSTEM
    • Telex RTS system
    • 24-4wire ports
    • 14 panels in ob - 3 external panels
    WIRELESS TALK-BACK INTERCOM SYSTEM
    • Clear-Com HME
    • Riedel Riface with MOTOROLA Base Station and Motorola Radios
    • Kenwood Base Station with Motorola Radios
    HYBRID SYSTEM
    • Glensound GSM Hybrid
    • Glensound Analog Landline Hybrid
    • Glensound Digital ISDN Hybrid

    COACH BUILD

    Length
    • 13.62 Meters
    Width stowed
    • 2.59 Meters
    Width expanded
    • 4.49 Meters
    Height
    • 4 Meters
    Weight
    • 20t
