trucks

Unit 10 – Middle East

Unit 10 – Middle East

Single expansion HD OBVAN, up to 18 Sony HDC1700/R cameras, 6 Vislink L1500 wireless system cameras with control, and controlled by TSL. It has the GVG Trinix core Router with GVG Kayak HD vision mixer, Blackmagic Hyperdeck Studio Pro tapeless recorders, Graphics system, and 4 EVS replay systems. This OB is equipped with Lawo MC2 66 audio console and Clear-Com intercom system.

    What’s a Rich Text element?

    The rich text element allows you to create and format headings, paragraphs, blockquotes, images, and video all in one place instead of having to add and format them individually. Just double-click and easily create content.

    Static and dynamic content editing

    A rich text element can be used with static or dynamic content. For static content, just drop it into any page and begin editing. For dynamic content, add a rich text field to any collection and then connect a rich text element to that field in the settings panel. Voila!

    How to customize formatting for each rich text
    • Headings, paragraphs, blockquotes, figures, images, and figure captions can all be styled after a class is added to the rich text element using the "When inside of" nested selector system.
    • ‍Headings, paragraphs, blockquotes, figures, images, and figure captions can all be styled after a class is added to the rich text element using the "When inside of" nested selector system.

    Headings, paragraphs, blockquotes, figures, images, and figure captions can all be styled after a class is added to the rich text element using the "When inside of" nested selector system.

    VIDEO EQUIPMENT

    CAMERA SYSTEM
    • Sony HDC1700/R (18+)
    SUPER SLOMO CAMERA SYSTEM
    • Sony HDC-3300R (2)
    ULTRA SLOMO CAMERA SYSTEM
    • Ikegami NAC HI-MOTION II
    WIRELESS CAMERA SYSTEM
    • Vislink L1500 (6)
    • DOMO BTX (4)
    CAMERA CONNECTION
    • Fiber Optic Lemo SMPTE
    CAMERA LENSES
    • CANON
    TRIPODS
    • CARTONI
    • VINTEN
    • SACHTLER
    • CAM-GEAR
    Control Room
    • Dual Production
    HD VISION MIXER
    • GVG kayak HD 3.5ME
    • 72 inputs - 36 outputs
    CHARACTER GENERATOR
    • VizRT
    • Title box
    PRODUCTION ROOM MONITORS
    • SONY 50inch (6)
    SHADING ROOM MONITORS
    • Sony 17inch (4)
    • Blackmagic (24)
    MULTIVIEWER SYSTEM
    • Evertz
    HD VTRS
    • Sony HDW M2000P (6)
    TAPELESS RECORDERS
    • HyperDeck Studio Pro (10)
    REPLAY SYSTEM
    • EVS XT2
    GLUE
    • AXON
    VIDEO MATRIX
    • GV TRINIX
    • 256 input – 224 output
    OB CONTROL
    • TSL
    WAVEFORM
    • Tektronix WFM 5000

    AUDIO EQUIPMENT

    AUDIO MIXING CONSOLE
    • Lawo MC2 66
    • Inputs local Ana:56 Dig:32 - Outputs: Ana:40 Dig:32
    MICROPHONES
    • Sennheiser
    MULTITRACK RECORDING
    • AVID Pro Tools
    AUDIO EFFECTS
    • Yamaha SPX 900
    • 360 SYSTEMS INSTANT REPLAY 2
    AUDIO MEASUREMENT
    • Decibel
    • VU meter
    INTERCOM SYSTEM
    • Clear-Com Matrix III
    • 28-4wire 4-2wire
    • 19 panels in ob - 3 external panels
    WIRELESS TALK-BACK INTERCOM SYSTEM
    • Clear-Com HME
    • Riedel Riface with MOTOROLA Base Station and Motorola Radios
    • Kenwood Base Station with Motorola Radios
    HYBRID SYSTEM
    • Glensound GSM Hybrid
    • Glensound Analog Landline Hybrid
    • Glensound Digital ISDN Hybrid
    COACH BUILD
    Length
    • 13.62 Meters
    Width stowed
    • 2.59 Meters
    Width expanded
    • 4.79 Meters
    Height
    • 3.95 Meters
    Weight
    • 20t
